Digital Gauge

DK50

(Digital Gauges) In an automobile, an electronic instrument cluster, digital instrument panel or digital dash for short, is a set of instrumentation, including the speedometer, that is displayed with a digital readout rather than with the traditional analog gauges

Features

High accuracy, rugged gauges. Suitable for installation on machine

  • Measuring range: 10 mm / 0.39
  • Accuracy: 2 μm
  • Resolution : 0.5 μm
  • Excellent resistance to workshop conditions.
  • High measuring force (10PR5/10PLR5)
  • Low measuring force (10NR5)
  • A variety of accessories available
  • Direct connected to A/B quadrature counter
  • Specifications

    # DF805S series Specifications -
    1 Model DK10NR5 / DK10PR5 / DK10PLR5
    2 Output A/B/Z phase voltage-differential line driver output(compliant with EIA-422)
    3 Maximum resolution※1 0.5 μm
    4 Measuring range 25mm
    5 Accuracy (at 20℃) 2 μm
    6 Reference point One location (at 1 mm/0.04" position of spindle movement)
    7 Maximum response speed 250 m/min
    8 Vibration resistance(10 ~ 2000 Hz) 1500 m/s2
    9 Impact resistance (11 ms) 1500 m/s2
