Digital Gauge

DK830S

(Digital Gauges) In an automobile, an electronic instrument cluster, digital instrument panel or digital dash for short, is a set of instrumentation, including the speedometer, that is displayed with a digital readout rather than with the traditional analog gauges

Features

High accuracy, 30mm stroke, and slim gauges for installation on machine.

  • Measuring range: 30mm
  • Accuracy: 1.3μm(DK830SR)))
  • Resolution: 0.1 μm
  • High response speed: 80m/min
  • Built-in reference point
  • High durability
  • Spline design applied to spindle bearings, thus improving reproduction of the detection accuracty.
  • Pneumatic push type(DK830SVR)
  • Protection design gradeIP53 / IP67
  • Specifications

    # DF805S series Specifications -
    1 Model DK830SR / DK830SLR / DK830SVR
    2 Measuring range 30mm
    3 Resolution 0.1 μmm
    4 Acucracy(at 20゜C / 68°F) 1.3 μm / 1.7 μm
    5 Measuring force Upperward: 0.5 ±0.35 N Horizontal: 0.6 ±0.35 N Downward: 0.7 ±0.35 N
    6 Operating temperture 0~50゜C
    7 Strage temperture -20~60゜C
    8 Maximum response speed 80 m/min
    9 Reference point response speed 80 m/min
