Digital Gauge

DK805S

(Digital Gauges) In an automobile, an electronic instrument cluster, digital instrument panel or digital dash for short, is a set of instrumentation, including the speedometer, that is displayed with a digital readout rather than with the traditional analog gauges

Features

Slim, compact, and having a high resolution of 0.1 μm maximum The maximum response speed has also further advanced.

  • Measuring range: 5mm
  • Accuracy:1 μm (high-resolution models), 1.5 μm (general-purpose resolution models)
  • Maximum resolution: 0.1 μm
  • Maximum response speed: 80 m/min (resolution 0.1 μm) 250 m/min (resolution 0.5 μm)
  • Built-in reference point
  • Excellent resistance to water and oil
  • Adopts a flexing-resistance cable
  • Specifications

    # DF805S series Specifications -
    1 Model High-resolution model / General-purpose resolution model
    2 Measuring range 5mm
    3 Maximum resolution 0.1μm / 0.5μm
    4 Accuracy (at 20°C) 1μm /1.5μm
    5 Measuring force (at 20°C) Upward:0.35±0.25N / Horizontal:0.40±0.25N / Downward:0.45±0.25N
    6 Working temp range 0~50℃
    7 Storage temp range -20~60℃
    8 Maximum response speed (*1) 80m/min (42m/min) / 250m/min (100m/min)
    9 Air driving Vacuum suction DK805SALR, DK805SAFLR, DK805SBLR, DK805SBFLR, DK805SALR5, DK805SAFLR5, DK805SBLR5, DK805SBFLR5
